Basic Info.
Model NO.
M-1375
Conditions of Use
Land Use Type/Traiker
Usage
Common Units
Landuse Type of Unit
Low Noise Automation Type
Excitation Mode
AC Rotating Exciter
Generator Fuel Tank
8-24hours Fuel Tank
Genset Certicificate
CE, ISO, EPA, Soncap
Brand
Yuchai, Yangdong, Fawde, Sdec, Weichai, Ricardo
Controller
Deepsea, Smartgen, Comaq etc
Alternator
Stanford, Leroy Somer, Marathon
Generator Cylinder
6L, 12V, 16V
Generator Warranty
1 Year or 1000 Working Hours
Generator Type
Open, Silent, Enclosed, Trailer, Container
Generator Logo
Customer′s Requirements
Water Tank Temperature
50 Degree
Transport Package
Disel Generator Packaged by Plywood
Specification
Iron Steel
Trademark
JET POWER
Origin
China
HS Code
8502131000
Production Capacity
400 Pieces One Month
Product Description
Genset Specification
Product Description
1. Our cooperate with famous diesel engine -powered by Deutz, Yuchai, Yangdong, Fawde, Sdec, Weichai, Ricardo, Weichai , etc..
2. Brushless alternator -- Stanford, Leroy Somer, Marathon, JET.
3. High-quality steel are thickness -- 2MM to 4MM
4. High density sound-absorbing material -- sound insulation, fireproofing
5. New design of turn-back type for air inflow & air outlet which can reduce the noise and advance engine efficiency.
6. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire
8. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
Engine
*Heavy duty diesel engine
*Four stroke, water cooled
*12V and 24V stater and charge alternator
*Cooling radiator and fan
*Maintenance free battery including ract and cable
*Flexible fuel connection hoses and manual oil sump drain valve
*Exhaust silencer
Alternator
*Brushless, single bearing, flexible disc
*Insulation class: H
*Protection class: IP23
*Self-exciting and Self-regulation
Canopy
*All canopy designed with modular principles
*All metal canopy parts painted by electrostatic polyester power paint
*Soundproof design ensure that the noise level be controlled in small scope
*Convenient to lift and move
*Easy to maintenance and operate
*Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.
Base Frame
*Base frame including position for forklift and crane
*Integral fuel tank
*Generator equipped with 8-24 hours fuel tank with fuel indicator, continuely working.
*Fuel tank easy to maintain and clean
*Anti-vibration pads are flexed between engine and alternator.
Control System
*Control, monitor and protect the Generator Set including:
*High water temperature
*Low oil pressure
*Over and under speed
*Over current
*Under/Over generator voltage
*Start and stop failure
*Low and high battery voltage
*Charge fail
*Emergency stop
Diesel generator types
diesel generator set
Generator diesel All new design for diesel generator set of open, Silent, Supper silent, Soundproof, Trailer type container
Generator Diesel Description
Our Service
one year or 1000 hours(diesel generator set ) whichever reach first from exfactory date.
1. During the guarantee period-
ur will provide the free easydamageable spare parts of alternator caused by our quality of production or raw material.
2. After expiration-
our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.
Our Company
FUZHOU JET ELECTRIC MACHINERY CO., LTD is a leadind manufacturer focus on Gasonline Generators, Disel Generators, Pump, Motor,Garden Machines. The factory is located in Fuan City Fujian provice, which is a well-konw electrical and machine city in China. For more convenient and efficient business, we set up company in HONGKONG and FUZHU CITY.
| Model | Standby Power | Prime Power | Engine | MITSUBISHI DIESEL ENGINE | Alternator | |||||||
| kVA | kW | kVA | kW | No. of Cylinders / Alignment | Bore / Stroke | Displacement (L) | Fuel Consumption of Full Load | Governing Type | Compression Ratio | Stanford | ||
| M-715 | 715 | 572 | 650 | 520 | S6R2-PTA-C/575KW | 6L | 170×120 mm | 29.96 | 124L/h | Electronic | 14.1 | HCI544F/570KVA |
| M-825 | 825 | 660 | 750 | 600 | S6R2-PTAA-C/645KW | 6L | 170×220 mm | 29.96 | 158L/h | Electronic | 14.1 | HCI634G/800KVA |
| M-1375 | 1375 | 1100 | 1250 | 1000 | S12R-PTA-C/1080KW | 12V | 170×180 mm | 49.03 | 247L/h | Electronic | 14.0 | PI734A/1260KVA |
| M-1500 | 1500 | 1200 | 1375 | 1100 | S12R-PTA2-C/1165KW | 12V | 170×180 mm | 49.03 | 272L/h | Electronic | 13.5 | PI734B/1400KVA |
| M-1650 | 1650 | 1320 | 1500 | 1200 | S12R-PTAA2-C/1277KW | 12V | 170×180 mm | 49.03 | 331L/h | Electronic | 13.5 | PI734C/1550KVA |
| M-1875 | 1875 | 1500 | 1700 | 1360 | S16R-PTA-C/1450KW | 16V | 170×180 mm | 65.37 | 370L/h | Electronic | 14.0 | PI734ES/1775KVA |
| M-2063 | 2062.5 | 1650 | 1875 | 1500 | S16R-PTA2-C/1600KW | 16V | 170×180 mm | 65.37 | 408L/h | Electronic | 13.5 | PI 734E/1900KVA |
| M-2200 | 2200 | 1760 | 2000 | 1600 | S16R-PTAA2-C /1684KW | 16V | 170×180 mm | 65.37 | 441L/h | Electronic | 14.0 | PI 734F/2080KVA |
1. Our cooperate with famous diesel engine -powered by Deutz, Yuchai, Yangdong, Fawde, Sdec, Weichai, Ricardo, Weichai , etc..
2. Brushless alternator -- Stanford, Leroy Somer, Marathon, JET.
3. High-quality steel are thickness -- 2MM to 4MM
4. High density sound-absorbing material -- sound insulation, fireproofing
5. New design of turn-back type for air inflow & air outlet which can reduce the noise and advance engine efficiency.
6. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
7. Generator equipped with 12V/ 24V DC battery with charger, battery connects wire
8. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
Engine
*Heavy duty diesel engine
*Four stroke, water cooled
*12V and 24V stater and charge alternator
*Cooling radiator and fan
*Maintenance free battery including ract and cable
*Flexible fuel connection hoses and manual oil sump drain valve
*Exhaust silencer
Alternator
*Brushless, single bearing, flexible disc
*Insulation class: H
*Protection class: IP23
*Self-exciting and Self-regulation
Canopy
*All canopy designed with modular principles
*All metal canopy parts painted by electrostatic polyester power paint
*Soundproof design ensure that the noise level be controlled in small scope
*Convenient to lift and move
*Easy to maintenance and operate
*Double open door on both sides of the Gensets. Spacious doors can check for every part of the engine and alternator.
Base Frame
*Base frame including position for forklift and crane
*Integral fuel tank
*Generator equipped with 8-24 hours fuel tank with fuel indicator, continuely working.
*Fuel tank easy to maintain and clean
*Anti-vibration pads are flexed between engine and alternator.
Control System
*Control, monitor and protect the Generator Set including:
*High water temperature
*Low oil pressure
*Over and under speed
*Over current
*Under/Over generator voltage
*Start and stop failure
*Low and high battery voltage
*Charge fail
*Emergency stop
Diesel generator types
diesel generator set
Generator diesel All new design for diesel generator set of open, Silent, Supper silent, Soundproof, Trailer type container
Generator Diesel Description
| Main standards | GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard |
| Prime output power | from 5KVA to 2500KVA |
| Rated voltage | 120V/240V, 220/380V, 230V/400V, 254V/440V etc. other voltage is optional |
| Generator phase and connecting | 3 phase, 4wire |
| Rated frequency | 50Hz@1500rpm or 60Hz@1800rpm |
| Alternator excited type | Brushless, self excited or PMG optional |
| Alternator Insulation | Class H |
| Alternator Protection | IP21 ~ IP23 |
| Voltage regulation | AVR automatic control 1% |
| Altitude above sea level | ≤1000 meters |
| Ambient air temperature | ≤40°C |
| Relative air humidity | ≤ 90% |
