Basic Info.
Appearance Shape
Round
Journal Surface Roughness
0.63-0.16μm
Process
Turing, Milling, Drilling
Transport Package
Wooden Box
Specification
OD100-OD3000
Trademark
ETERNAL
Origin
China
HS Code
8412909000
Production Capacity
1000 Ton/Month
Product Description
Product Description
| GB | ГOCT | EN | DIN | W.N. | JIS | AISI/SAE | |
| 15CrMn | 16MnCr5 | 16MnCr5 | 1.7131 | 5115 | |||
| 20CrMn | 20MnCr5 | 20MnCr5 | 1.7147 | 5120 | |||
| 12CrMo | 12XM | 13CrMo44 | 1.7335 | 4119 | |||
| 15CrMo | 15XM | 15CrMo5 | 1.7262 | SCM415 | |||
| 20CrMo | 20XM | 20CrMo5 | 1.7264 | SCM420 | 4118 | ||
| 25CrMo | 30XM | 25CrMo4 | 1.7218 | ||||
| 30CrMo | SCM430 | 4130 | |||||
| 35CrMo | 35XM | 34CrMo4 | 1.722 | SCM435 | 4135 | ||
| 42CrMo | EN19 | 42CrMo4 | 1.7225 | SCM440 | 4140 | ||
| 50CrMo4 | 1.7228 | ||||||
| 40Cr | 40X | 41Cr4 | |||||
| 38XC | |||||||
| 25Cr2MoV | 25X2M1Φ | 24CrMoV55 | 1.7733 | ||||
| 50CrVA | 50CrV4 | 1.8159 | SUP10 | ||||
| 31CrMoV9 | 1.8519 | ||||||
| GCr15 | 100Cr6 | 100Cr6 | 1.3505 | 52100 | |||
| 20CrNiMo | 20XHM | 20NiCrMo2-2 | 21NiCrMo2 | 1.6523 | SNCM220 | 8620 | |
| 20XH3A | |||||||
| 20X2H4A | |||||||
| 17CrNiMo6 | 1.6587 | ||||||
| 18CrNiMo7-6 | 1.6587 | ||||||
| 34CrNiMo6 | 1.6582 | VCN150 | |||||
| 34NiCrMo16 | 35NiCrMo16 | 1.2766 | |||||
| 30CrNiMo8 | 1.658 | VCN200 | |||||
| 39NiCrMo3 | 1.651 | ||||||
| 34CrAlNi7 | 1.855 | ||||||
| 38CrMoAl | 38X2MОA | 41CrAlMo7 | 1.8509 | ||||
| 40CrNiMo | EN24 | 40NiCrMo8-4 | 1.6562 | SNCM439 | 4340 | ||
| 40CrNi | 40XH | 40NiCr6 | 1.5711 | ||||
| 20CrMnMo | 18XTM | SCM421 | |||||
| 40CrMnMo | 40XTM | SCM440 | |||||
| 30XTCA | |||||||
| 38XTH | |||||||
| 40XH2MA | |||||||
| 40X2H2MA | |||||||
| 38XH3MA | |||||||
| 38XH3MΦA |
Jiangyin Eternal Heavy Industry Co. Ltd was established in 2008, the main products include: all kinds of forging rolls, patio drilling rig drilling tools, and various of large hydraulic cylinders.
The company produces various of forging rolls, which are widely used in steel mill rolling mills, copper and aluminum strip rolling mills, cement rotary kilns, roll presses, ore crushers, paper making rolls, rubber and plastic rollers, cylinder plungers, piston rods, hydraulic press tie rods, etc. The outer diameter of the roller can reach 800mm, and the length can reach 6000mm. The length of the piston rod and pull rod can reach 11 meters.
The company has 15 years of experience in the production of cutterheads and drilling tools for patio drilling rigs. The diameter of the cutterhead can reach 6 meters, and the drill pipe is from 8"-13". Products have been exported to many countries, including South Africa, Brazil, Peru, Mexico, Vietnam, Russia and so on.
The various large hydraulic cylinders and high-precision AGC servo cylinders produced by the company are widely used in forging machinery, engineering and mining machinery, water conservancy engineering, ship machinery, port machinery, hydraulic lifting equipment, etc. Up to now, large cylinders have been widely used in various hydraulic presses, extruders, die-casting machines, injection molding machines, etc. In 2008, servo cylinders for steel mill rolling mills with a bore of 950mm were successfully exported to Poland. In 2009, the hydraulic cylinder with a stroke of 10 meters was successfully exported to the Pakistan water conservancy project. In October 2016, large cylinders weighing 90 tons per unit have been successfully exported to Russia. The range of cylinders that the company can produce: cylinder diameter 1000mm, stroke 12 meters, test pressure up to 50MPA.
The company has built a heavy workshop of 8,000 square meters. The workshop is equipped with double-decker driving. The lifting height can reach to 16 meters, and the design lifting capacity is 50 tons. The company has perfect machining equipment, heat treatment equipment and testing equipment, including: 11m horizontal lathe, vertical machining center, digital display boring and milling machine, gantry machining center, cylindrical grinding, various types of CNC lathes, 13m deep hole boring machine, 13m CNC deep hole honing machine, tempering furnace with a length of 6 meters, a quenching tank with a length of 10 meters, a medium frequency quenching machine with a height of 6 meters, and a straightening machine with a pressure of 500 tons. Testing equipment includes: intelligent pressure test bench, ultrasonic flaw detector, magnetic particle flaw detector, coating thickness gauge, roughness tester, etc. The company is committed to providing customers with a full range of system solutions, to revitalize the national equipment to contribute, in the past 15 years, the company continues to develop the market and research and development of new products, the company's products have been exported to more than 50 countries and regions.
The company has passed ISO9001, ISO14001, ISO45001 system certification. The company sincerely hopes to carry out technical exchanges with domestic and foreign counterparts, and looks forward to cooperating with customers in various industries, Jiangyin Eternal Heavy Industry Co. Ltd welcomes your visit!
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2008,sell to Domestic Market(36.00%),Eastern Europe(21.00%),Southeast Asia(16.00%),South America(12.00%),North America(9.00%),Northern Europe(4.00%),South Asia(2.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;
3.what can you buy from us?
Roll and Rollers.
4. why should you buy from us not from other suppliers?
We have rich experience on casting, forging and heat treatment.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES; Accepted Payment Currency:USD,EUR,CNY; Accepted Payment Type: T/T,L/C,D/P D/A,Western Union; Language Spoken:English,Chinese,Portuguese,Russian
